High precision PP - 50 universal tool grinder

  • >=1 Pieces
    $7,950.00
Model Number:
BFP-50
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Universal
Warranty:
1 year
After-sales Service Provided:
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Overseas third-party support available
Place of Origin:
Taiwan, China
Brand Name:
Bafang
Voltage:
110V/220V/380V
Certification:
ISO9001
CNC or Not:
CNC
Dimension(L*W*H):
100 x 85 x 154cm
Power (kW):
0.55
Applicable Industries:
Manufacturing Plant, Machinery Repair Shops
Key Selling Points:
Multifunctional
Weight (KG):
320
Horizontal travel of the oprating table:
230mm
Longitudinal travel:
180mm
elevating distance of wheel head:
120mm
rotating angle of wheel head:
360°
rotating angle of Lifting column:
three-dimensional 360°
area of operating table:
620 x 190mm
grinding wheel size:
125 x 50 x 31.75mm
speed of grinding wheel:
3600RPM
horse power and voltage of motor:
3/4HP, 110V/220V/380V
Supply Ability
Supply Ability:
50 Piece/Pieces per Day high precision PP - 50 universal tool grinder
Packaging & Delivery
Packaging Details
wooden box
Port
qingdao

High precision PP - 50 universal tool grinder



.png

Feature:

1, This machine can be according to the need of grinding tool to match different attachments, and grinding: drill, tap, end milling cutter, R milling cutter, R type tool, chamfering cutter, side milling cutter, round rods, round cutter, reamer, rolling shaping cutter and other cutting tools;

2, Motor can rotate 360 °, increase the cutter grinding of handling.

3, workbench adopt imported high precision linear ball slide rail, the bed platform balance,  It is easy to operate.

4, the machine adopts high strength and ductility FC30 cast iron, which can keep machine precision;







Product parameter:

Model

PP-50

Horizontal travel of the operating table

230mm

Longitudinal travel of the operating table

180mm

Area of the operating table

620*190mm

Elevating distance of wheel head

120mm

Rotating angle of wheel head

360°

Grinding wheel size



180 x 25 x 31.75mm

125 x 50 x 31.75mm

Speed of grinding wheel

3600rpm

Horse Power and voltage of motor

3/4HP, 110V/220V/380V

Packing size

100 x 85 x 154cm

N.W/G.W

260kg/300kg



.jpg

PP50 (1).jpgPP50 (2).jpgPP50 (3).jpgPP50 (4).jpgPP50 (5).jpgPP50 (6).jpg






.jpg
