home use large wind generator turbine 10kw 5kw 3kw 2 kw

FOB Reference Price:Get Latest Price
$4,500.00 - $6,500.00 / Sets | 1 Set/Sets (Min. Order)
Type:
Wind Power Generator
Rated Power:
3kw
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
FF
Model Number:
BF-10K
Rated voltage:
220V/380V
Rated power:
10kw
Rated wind speed:
10m/s
380V Start-up wind speed:
3m/s
Top net weight:
600kg
Wheel diameter:
8.2m
Blades material:
reinforced glass fiber
Supply Ability
Supply Ability:
100 Set/Sets per Day
Packaging & Delivery
Packaging Details
WOODEN
Port
QINGDAO

wind generator 10kw Features:



1.Carbon steel body, compact, safe.

2.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure

3.Patented permanent magnet ac generator with special stator,effectively reduce torque

4.Tail adopts mechanical yaw technique, making it survive storm and run safely.

5.With epoxy zinc rich primer and polyurethane anti-corrosion treatment

6.Intelligent automatic grease injection, which ensure flexible running and durable life.



wind generator  Parameter:

MODEL

-1000

-2000

-3000

-5000

-10K

Rated power

1000W

2000W

3000W

5000W

10000W

Max power

1500W

2500W

4000W

7000W

13000W

Rated Voltage

48V

96V

120V(220/240v)

220V(240v)

380V(220V/240)

Start-up Wind Speed

3m/s

3m/s

3m/s

3m/s

3m/s

Rated Wind

10m/s

10m/s

10m/s

10m/s

10m/s

Rotate Speed

500r/m

600r/m

500r/m

500r/m

220r/m

Safety Wind Speed

45m/s

45 m/s

45m/s

45m/s

45m/s

Gross Weight

37kg

48kg

205kg

260kg

520kg

Diameter of Blade

2.8m

3.2m

5.6m

6.3m

8.2m

Tower height

6m

6m

9m

9m

12m

Suggested Battery

150Ah*4

100Ah*8

150Ah*10

100Ah*18

150Ah*31

Blade Quantity

3

Motor

3PHASE AC



Environment Tem

-40℃-80℃
