Top quality nurable machinery electric hydraulic self propelled scissor lift

FOB Reference Price:Get Latest Price
$9,300.00 - $13,230.00 / Units | 1 Unit/Units (Min. Order)
Model Number:
GTJZD SERIES
Rated Loading Capacity:
113KG-320KG
Max. Lifting Height:
13.8m
Lead Time:
Quantity(Units) 1 - 5 >5
Est. Time(days) 3 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
BAFANG
Lift Mechanism:
Scissor Lift
Lift Drive / Actuation:
Electric Motor
Min. Lifting Height:
13.8m
Table Size:
2.26*1.13*1.1m
Overall Dimensions:
2.475*1.17*2.149m
Weight:
1750kg-2860kg
Certification:
ISO/SGS
Warranty:
1 Year
After-sales Service Provided:
Online support
Packaging & Delivery
Port
QINGDAO, CHINA
Lead Time :
Quantity(Units) 1 - 5 >5
Est. Time(days) 3 To be negotiated

Top quality nurable machinery electric hydraulic self propelled scissor lift

Product Specifications

GTJZ 06

GTJZ 08

GTJZ 10

GTJZ12

working height

78m

10m

12m

13.8m

platform height

6m

8m

10.0m

12m

platform height stowed

1.07m

1.23m

1.37m

1.49m

platform length

1.67m

2.27m

2.27m

2.27m

platform extension length

0.9m

0.9m

0.9m

0.9m

platform width

0.76m

0.81m

1.17m

1.17m

Overall Height

2.18m

2.34m

2.48m

2.59m

Overall length

1.86m

2.42m

2.42m

2.42m

Overall Width

0.76m

0.81m

1.17m

1.17m

Wheelbase

1.31m

1.87m

1.87m

1.87m

Ground Clearance

0.1m

0.1m

0.1m

0.1m

Lift capacity

230kg

230kg

320kg

320kg

Lift Capacity-Extension Deck

113kg

113kg

113kg

113kg

Weight

1415kg

2250kg

2440kg

2860kg

Drive Speed(Platform Elevated)

0-5km/h

0-3.5km/h

0-3.5km/h

0-3.5km/h

Drive Speed(Platform Lowered)

0-0.8km/h

0-0.8km/h

0-0.8km/h

0-0.8km/h

Turning Radius-outside

0

0

0

0

Turning Radius-inside

1.64m

2.10m

2.14m

2.14m

Battery

6v*4/180Ah

6v*4/180Ah

6v*4/180Ah

6v*4/210Ah

Charger

24V/25A

24V/25A

24V/25A

24V/25A
