Hot sale portable pneumatic percussion drill

FOB Reference Price:Get Latest Price
$150.00 - $300.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 7 Negotiable
Report Suspicious Activity
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Model Number:
Air Drill
Average Air Consumption:
Less than or equal to 12 liters / sec
Air drill
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden case
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 7 To be negotiated

Hot sale portable pneumatic percussion drill


Multi-purpose pneumatic drills primarily for mounting on a rock, brick, concrete pipes and other components, erection of power lines, install anchor bolts, chemical plants, refineries, construction, heavy industry, the risk of wet gas tunnel, underwater and narrow space job; especially in the mines, pneumatic explosion-proof no spark to better reflect its security.
How it works: the air pressure pipe joints of pipe into the air regulator and pressure lever carried into the cylinder, and then by the fader or rotary impact line into pure shock or impact so as to achieve the role of rotation.





4.5 kg

Piston stroke

34 mm

Cylinder diameter

10 mm

impact energy pressure is 0.4Mpa

2.5 Joule

impact frequency

not less than 48 Hz

Air consumption

Less than or equal to 12 liters / sec

Specifications of drill bit width

Diameter 8/12/14/16/18/20/24 mm

Maximum drilling depth

240 mm

Impact Drill Dimensions

366 * 185 * 76mm


shank, push lever, cylinder, head, putting other components
